Honeywell CN80

Ultra-rugged mobile computer with touchscreen and QWERTY or numeric keypad

IP ratingIP65 / IP67
Weight500 g

Model: CN80
Brand: Honeywell

Ultra-rugged mobile computer with a 4.2-inch display, Snapdragon 660 and a 5,800 mAh battery. 40-key QWERTY or 23-key numeric keypad, 1D/2D scanner, IP67 and 3 m drop.

On order

Delivered within one week of payment.

from 14 700 MDL Price incl. VAT

The price is set individually: send a request and we will prepare a quote.

Request a quote Call

Ask via messengerWhatsApp Viber Telegram

BrochuresSpec sheet (EN) EN

01Description

Honeywell CN80 combines a touchscreen with a physical keypad and is built on the Mobility Edge platform with Android. It ships with an N6603ER or EX20 (near/far) scan engine and an LTE modem.

Key features

Snapdragon 660 octa-core 2.2 GHz, 3 GB/4 GB RAM, 32 GB flash; microSD up to 512 GB
4.2-inch FWVGA 854 x 480 display, outdoor viewable; touch for finger, glove or stylus
N6603ER or EX20 Near/Far scan engine (0.15 m to 15.2 m), 1D/2D
LTE Cat13, Wi-Fi 802.11 a/b/g/n/ac, Bluetooth 5.0, integrated NFC
IP67 and IP65, 3 m drop to concrete, over 2,000 tumbles of 1 m
5,800 mAh Li-Ion battery; cold storage (-30°C) and non-incendive versions

Typical uses

Logistics, warehouse, field mobility and cold storage.

Request a quote.

02Specifications

Platform

Operating system	Android; guaranteed from 7.1 to at least 11 (R); security updates via Honeywell Sentinel
Processor	Qualcomm Snapdragon 660 octa-core, 2.2 GHz
Memory (RAM / storage)	3 GB/4 GB RAM, 32 GB flash; microSD up to 512 GB

Display and data capture

Display	4.2" FWVGA 854 x 480, LCD with backlight, outdoor viewable, multi-touch capacitive
Input	Touchscreen + physical keypad
Scanner	Honeywell N6603ER (1D/2D) or EX20 Near/Far (1D/2D, 0.15 m to 15.2 m)
Camera	Rear 13 MP color with autofocus

Connectivity

Wi-Fi	IEEE 802.11 a/b/g/n/ac, 2x2 MIMO
Cellular	WWAN LTE Cat13 (400 Mbps), 3G, GSM; two micro-SIM slots
Bluetooth / NFC	Bluetooth 5.0 and BLE (Class 1.5); integrated NFC

Power and durability

Battery	Li-Ion 3.85 V, 5,800 mAh with battery diagnostics
IP rating	IP65 / IP67
Drop resistance	3 m (10 ft) onto concrete at room temp (MIL-STD 810G); 1.8 m at -20°C to 50°C
Operating temperature	-20°C to 50°C; cold storage unit -30°C to 50°C
Weight	500 g (N6603ER) / 550 g (EX20), with battery
